| Supply voltage | AC100/110V 50/60Hz | |||||
| AC200/220V 50/60Hz | ||||||
| Manufactured based on your preferred voltage. | ||||||
| Mount | Screw-in PF 3/4" | |||||
| Power consumption | 1.5W | |||||
| Contact output | 1C contact 250V AC6A(resistance load) | |||||
| Detection torque | Approx 4.9N·cm | |||||
| Slip torque | Approx 24.5~29.4N·cm | |||||
| Revolutions perminute | 1R.P.M | |||||
| Material | Case and flange | Aluminum alloy | ||||
| Shaft and paddle | SUS-304 | |||||
| Seal | Nitnle rubber | |||||
| Temperature ranges | Tank inside Max60°C | |||||
| Tank outside Max55°C | ||||||
| Max.pressure | Tank inside 0~196kPa | |||||
| Painted color | Munsell 7.5BG 4/1.5 | |||||
| Lead wire | VCT0.75 sq with 5-core 500mm | |||||
